The GPN 200 Type B protective caps are designed for male end connectors in accordance with DIN EN 837-1 and DIN EN 837-3. The easy-to-grip, knurled outer wall ensures easy removal.
see table
see table
|
Applicable for
|
Dimensions
|
|||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Product | External Thread | External Diameter | G | (O) | Order no. |
Piece Price
|
Item selection
|
Quantity | ||
| GPN 200 / 1040 PCR-PE / LDPE yellow | M 12 x 1.5 | 12 | 12 | 16 | 20010401073 | Login | To the product | |||
| GPN 200 / 1040 PCR-PE recycling blue | M 12 x 1.5 | 12 | 12 | 16 | 2001040RB61 | Login | To the product | |||
| GPN 200 / 1040 LDPE nature | M 12 x 1.5 | 12 | 12 | 16 | 20010400000 | Login | To the product | |||
| GPN 200 / 790 PCR-PE / LDPE yellow | M 20 x 1.5 | 20 | 20 | 26 | 20007901073 | Login | To the product | |||
| GPN 200 / 790 PCR-PE recycling blue | M 20 x 1.5 | 20 | 20 | 26 | 2000790RB61 | Login | To the product | |||
| GPN 200 / 790 LDPE nature | M 20 x 1.5 | 20 | 20 | 26 | 20007900000 | Login | To the product | |||
| GPN 200 / 1041 PCR-PE / LDPE yellow | G 1/4 | 13 | 12 | 16 | 20010411073 | Login | To the product | |||
| GPN 200 / 1041 PCR-PE recycling blue | G 1/4 | 13 | 12 | 16 | 2001041RB61 | Login | To the product | |||
| GPN 200 / 1041 LDPE nature | G 1/4 | 13 | 12 | 16 | 20010410000 | Login | To the product | |||
| GPN 200 / 791 PCR-PE / LDPE yellow | G 1/2 | 21 | 20 | 26 | 20007911073 | Login | To the product | |||
| GPN 200 / 791 PCR-PE recycling blue | G 1/2 | 21 | 20 | 26 | 2000791RB61 | Login | To the product | |||
| GPN 200 / 791 LDPE nature | G 1/2 | 21 | 20 | 26 | 20007910000 | Login | To the product | |||
